| Basic Information | ||
|---|---|---|
| Capacity | 12v 7.5Ah | |
| Input Voltage Range | Voltage Range: Single-phase 120Vac-288Vac Input Voltage: Single-phase 120Vac-288Vac |
|
| Output Voltage | Single-phase 220Vac | |
| Output Frequency | 45Hz-65Hz, Frequency precision 0.25% | |
| Noise Level | <55dB | |
| Battery | Battery brand: Always/Star/Equivalent Battery Capacity: 12v 7.5Ah Battery Qty: 16 units Battery Cabinet: Internal Battery Charging capability: >6h for 90% re-charging of standard model |
|
| Rectifier Type | IGBT rectifier | |
| Input Features | ||
| Power Factor | >=0.99 for single phase/>0.95 for three-phase | |
| Output Features | ||
| Backup Time | Standard back up (15-30)min | |
| Power Factor | 0.9 | |
| Transfer Time | 00 | |
| Waveform | Sinewave | |
| Rated power | 6KVA/48KW | |
| Manufacture Warranty | ||
| Warranty | 01 year warranty | |
